12-Point Bi-Hex Socket, 3/8''

Reference code: 9226090001
EAN Code: 3303809226099

Request the posting of this product in SEAP/SICAP

12-POINT BI-HEX SOCKET, 3/8'' - Description

NF ISO 2725 - DIN 3124

12-POINT BI-HEX SOCKET, 3/8'' - More Details

ERGONOMY: The socket handling is easy thanks to its external shape: Good grip. The form of the sockets is marked so that they can be found easily. Chrome vanadium steel, best material for sockets and other accessories. Removing the sharp angles of the squares increases their resistance. Chrome-Vanadium steel bushing, the best material for the manufacture of sockets and accessories.

Specifications

Dim mm	ØDb mm	ØDa mm	L mm	g	G
7	16,9	10,7	63	48	E	9226070001	5	3303809226075
8	16,9	11,9	63	49	E	9226080001	5	3303809226082
9	16,9	13,2	63	52	E	9226090001	5	3303809226099
10	16,9	14,4	63	52	E	9226100001	5	3303809226105
11	16,9	15,7	63	60	E	9226110001	5	3303809226112
12	16,9	16,4	63	73	E	9226120001	5	3303809226129
13	17	17,8	63	74	E	9226130001	5	3303809226136
15	18	21	63	84	E	9226150001	5	3303809226150
16	18	21,8	63	97	E	9226160001	5	3303809226167
17	19	23,8	63	123	E	9226170001	5	3303809226174
18	20	24,6	63	124	E	9226180001	5	3303809226181
19	20	25,7	63	138	E	9226190001	5	3303809226198
20	20	27,2	63	157	E	9226200001	5	3303809226204
21	22	28	63	164	E	9226210001	5	3303809226211
22	22	29,7	63	188	E	9226220001	5	3303809226228
23	22	31	63	194	E	9226230001	5	3303809226235
24	22	31,9	63	210	E	9226240001	5	3303809226242
