For simple and safe intensive vertical installation3 installation options: horizontal, under slopes and vertical
LOW LOADING HEIGHT

• - 68 cm for the 4m model
• - 81cm for the 4.50m model

ERGONOMIC HANDLEBARS - PATENTEDThe handlebar makes handling the plates ultra-simple, and is equipped with 2 levers:

• - 1 for 90° pivoting of the beam and arms
• - 1 for tilting the head

SAFETY SYSTEM consisting of 2 cables - PATENTED

• - 1 working cable
• - 1 anti-fall safety cable

FOLDING and adjustable PADS for fitting plasterboard of all widths 0.60m, 0.90m and 1.20m - PATENTED
FLOOR SPACE

• - Horizontal installation and under slopes: 1.02 x 1.02 x 1.02 m
• - Vertical installation: 1.09 x 0.94 x 0.94 m

EASY TO HANDLE

• - Ergonomic handlebars for effortless handling of the panels
• - Braking system integrated into the non-return winch, attached to the guide handle. This makes the machine extremely manoeuvrable
• - 3 Ø 160 mm wheels for easy movement over rough surfaces, particularly with heavier fireproof panels or gypsum and cellulose boards, fitted with a locking system
• - 2 transport wheels for moving when closed
• - Low loading height

GUARANTEED SAFETY8 anti-slip pads to keep the plate firmly in place

• - Offset handle: the guide handle is not located under the plate. The user is off-set to give better visibility and more control. This also means you don't have to put your head under the Levpano when descending.

PRACTICAL

• - Quick to assemble and dismantle
• - A real platform on which you can climb to fix the plate.

FEATURES

• - Aluminium column for a payload of 80 kg
• - Platform: 0.50 x 0.62 m, thickness: 25 mm, height: 0.49 m and strength: 150 kg
• - Plasterboard of all widths: 0.60 m, 0.90 m and 1.20 m, thanks to the retractable and adjustable shoes on the Levpano arm (patented) and thanks to the adjustable arms opposite the shoes
• - Maximum opening of end arms: 3.10 m
• - Minimum height of horizontal plate: 1.19 m = work surface.

OUR GUARANTEES :

• - Complies with CE standards and European Directive 2006/42/EC
• - Compliance examination carried out by SOCOTEC
• - Each Levpano is individually assembled and tested
• - Delivered pre-assembled

WORKPLATFORM supplied with the appliance, adaptable to horizontal or under-roof configurations
