Bolt Cutters Tube Arms
Loading...
- Reference code: 0515060610
- EAN Code: 3303800515048
Request the posting of this product in
SEAP/SICAP
BOLT CUTTERS TUBE ARMS - Description
Axial section. Tube arm. Neoprene handles.
BOLT CUTTERS TUBE ARMS - More Details
PERFORMANCE OF CUTTING. Axial cutting. Cutting capacity upto 12 mm diameter. Long lasting forged blades. High resistance chrome vanadium molibdenum steel. Hardened and forged blades for a long lasting quality (cutting zone hardness: 45 HRC). Exclusive geometry (axis brought out of centre) for a bigger opening. Screwed heads for a higher compactness of bolts. Protection sheet against any untimely screw off
QUALITY OF FINISHING. Epoxy painting boiled in furnace for an excellent resistance, 60Β΅m thickness guaranteedSheathed elastomer handles for a good grip and amelioration of ergonomy. Light tube arms
SIMPLICITY OF USE. Adjusting of the blades distance using an eccentric screw. Tip: leave a day between the 2 blades to avoid any deterioration. The change of blades is done by 2 screws.
QUALITY OF FINISHING. Epoxy painting boiled in furnace for an excellent resistance, 60Β΅m thickness guaranteedSheathed elastomer handles for a good grip and amelioration of ergonomy. Light tube arms
SIMPLICITY OF USE. Adjusting of the blades distance using an eccentric screw. Tip: leave a day between the 2 blades to avoid any deterioration. The change of blades is done by 2 screws.
Specifications
| L mm | Maximum of cutting capacity 80 daN/mm2 | Maximum of cutting capacity 140 daN/mm2 | E mm | B mm |  g | G |  | ||
|---|---|---|---|---|---|---|---|---|---|
| 450 | Γ 8 mm | Γ 6 mm | 8 | 69 | 1850 | G30 | 0515060610 | 1 | 3303800515048 |
| 600 | Γ 10 mm | Γ 7 mm | 10 | 85 | 2555 | G30 | 0515070610 | 1 | 3303800515017 |
| 750 | Γ 12 mm | Γ 9 mm | 11 | 100 | 4620 | G30 | 0515080610 | 1 | 3303800515024 |
| 900 | Γ 14 mm | Γ 10 mm | 13 | 110 | 5825 | G30 | 0515090610 | 1 | 3303800515031 |
| 1050 | Γ 16 mm | Γ 12 mm | 15 | 128 | 7985 | G30 | 0515010001 | 1 | 3303800008168 |
